ID # 25080034

Case IH RD163

Call for Price
RD163 RD163
The RD163 is compatible with the WD2104 and WD2504 and has a cutting width — 16 ft 1 in (4.9 m). Its Hi-Contact rolls are perfect for legume-type crops in low-humidity climates.
​​​Quick Specs​
Cutting Width:16 ft (4.9 m)
Minimum Cutting Height: 0.70 in (18 mm)
Number of Discs: 10
RD163 Highlights
  • Cutting width — 16 ft 1 in (4.9 m)
  • Compatible — WD1903 and WD2303
  • Rubber-on-rubber conditioning rolls
  • Steel-on-steel conditioning rolls
  • Flail conditioner (For grass like crops)
  • Hi-contact rolls for legume-type crops in low-humidity climates
  • Conditioning rolls are mounted in "modules" that are easily removed and exchanged to suit different crops and conditions throughout the season
  • Complete removal of the conditioning roll module allows for cutting without conditioning, if desired
Rotary Disc Headers
 Case IH RD series rotary disc headers offer quality cutting at uncompromising speed in tough crop conditions with minimum maintenance.
Disc Modules: Rugged and Easy Service, Repair or Replacement Disc Modules: Rugged and Easy Service, Repair or Replacement
  • Individually sealed bearings , gears and lubricant – damage or contamination to one disc doesn't spread to another
  • Complete gear lubrication , even when cutting on slopes or at an angle
  • Austempered discs for extra hardness and durability in punishing conditions
  • A protective liner in the hood helps reduce rock damage
  • Heavy-duty gears and cross shafts
Sale Type
Case IH
Roll / Rotor Speed, Rpm
Roll / Rotor Length, In (mm)
102 (2591)
Roll / Rotor Diameter, In (mm)
10.375 (264)
disc header
Cutting Width, Ft In (m)
16' 1" (4.90)
Conditioner Type, Roll Or Flail
Conditioner Removable Or Can Be Omitted
disc cutterbar
Knives Per Disc
Number Of Discs
Disc Cutting Diameter, In (mm)
24.3 (618)
sales literature
Literature Date
July, 2011
Literature Number
crop movement-cutterbar to conditioner
Transition Description, Cutterbar To Conditioner
Full width auger w/ discharge paddles
