 MANEUVERABILITY AND PERFORMANCE
The JCB 525-60 Agri Plus telescopic handler comes with 4WD as standard. Opt for our limited slip differential to maximize traction on slippery surfaces. - 2-speed transmission allows you to select high and low speeds. The low speed setting complies with building site speed regulations, while high speed is ideal for road travel.
- A hydrostatic transmission makes it easy to maneuver with precision even in cramped spaces. The driveline works in parallel with the braking system too; a transmission dump on the foot brake offers superb multi-functioning and increased power during loading and re-handling.
- A low height of 6 ft 2 inches and a narrow width of 6 ft enables this JCB telescopic handler to access the smallest of operating environments. With a compact wheelbase and large steering lock angles, a tight turning radius and superior maneuverability are assured.
|
EFFICIENT BY DESIGN
The 525-60 Agri Plus telescopic handler is equipped with a potent JCB Diesel by Kohler T4 Final engine which produces 220lb-ft (300Nm) of torque at just 1,500rpm, and doesn’t need a costly DPF or DEF after-treatment. - Because it produces peak levels of torque at revs as low as 1,500rpm, this engine can provide fuel-efficient matching of the transmission and hydraulics.
- Most Tier 4 Final engines use a Diesel Particulate Filter (DPF) or SCR, requiring additional DEF fluid level maintenance – this JCB Diesel by Kohler engine doesn’t.
- JCB’s new-look telescopic handler exterior isn’t purely cosmetic; the cooling fan airflow is now angled upwards, reducing time-consuming dust build-up.
|
COMFORT AND EASE OF USE
The JCB 525-60 Agri Plus telescopic handler has a large, spacious cab with a wide access door; inside, there’s a radio speaker and plenty of storage. Tinted cab glass is fit as standard, reflecting 30% of the sun’s energy to increase comfort. - This telescopic handler has all-new instruments and a hi-res TFT screen. Intuitively laid-out control switches are backlit for optimum night recognition. You can also choose from a variety of seating options to suit all operators and applications.
- So that you can tailor your telescopic handler for any climate, you can choose from canopy or cab options. Air conditioning is available for all cabs, ensuring the perfect working environment.
- Controlling a JCB 525-60 Agri Plus is comfortable, precise and smooth: there are single lever electro servo controls with proportional auxiliaries.
|
SAFETY AND SECURITY
Bystanders are safeguarded by our standard-fit reversing alarm and this telescopic handler also has hose burst check valves (HBCVs) to protect the rams from collapse in the event of a hose failure. - For added peace of mind, this telescopic handler’s cab is ROPS (Rollover Protection System) and FOPS (Falling Objects Protection System) certified, keeping its operator protected at all times.
- All-around visibility is superb via the large sunroof, opening rear window, fold-back upper door, and compact JCB Diesel by Kohler engine unit with its low-level sloping hood. Rear visibility is class-leading thanks to our unique low profile rear chassis and boom.
- Cab-mounted front and rear worklights provide great visibility. To make it even better (especially when loading at height in dark conditions), opt for our boom-mounted worklights.
- JCB LiveLink’s telematic GPS tracking provides invaluable real-time location data on your telescopic handler. Geofencing alerts help to ensure your machine is only being used in your chosen areas.
|
 STRENGTH AND DURABILITY
A JCB telescopic handler is fit with a tough inverted U-shaped boom pressing with fully welded closing plates. For extra strength, we’ve reduced the number of joints and stress points across our integrated boom nose and one-piece closing plate. - Hoses are routed through the boom for maximum protection, while boom overlaps of up to 3.2ft ensure ultimate strength and durability.
- Side-mounted,recessed engine hoods and fold-up rear lights are designed to avoid on-site damage to your telescopic handler. For comprehensive long-term corrosion protection, we dip the cab in electrophoretic alloy before painting it.
- The JCB telescopic handler range’s stringent testing program has included prolonged high stress loading of the chassis, boom and other key components, as well as repeated transmission use over thousands of cycles.
- The Tier 4 Final engine builds on the proven success of the JCB EcoMax platform. Since the start of the engine program we have achieved over 200,000 hours of testing across the toughest applications and environments.
- Every JCB telehandler benefits from a one-piece fully welded chassis which maximizes strength and minimizes weight. Opt for front and top screen roof guards to increase protection from falling objects.
- At JCB, we make our own hydraulic cylinders, cabs, axles, transmissions and engines – all designed to work in perfect harmony for optimum reliability.
- JCB telescopic handlers boast 500hrs extended service intervals and simplified maintenance procedures, and with our worldwide dealer network you have a ‘one stop shop’ for parts and service.
- Our telescopic handlers also remain highly desirable long after their initial purchase. So much so that, throughout the world, JCB telescopic handlers can boast premium residual values.
|
