H&S PS6138 237 Cu. Ft. Struck Per ASAE S324.2 PowerSpread Manure Spreader

Features 373 cu ft heaped capacity per ASAE S324.2 A center drive shaft with a torque limiting clutch provides power and protection to the bottom driven monobloc gearbox. Dual hydraulic cylinder guillotine/metering style endgate Patented reverse flighting creates a more even spread pattern. 1/2″ thick vertical beater flighting 5/8″ marine log chain apron featuring a l...

Overview

H&S PS6138 237 Cu. Ft. Struck Per ASAE S324.2 PowerSpread Manure SpreaderFeatures

  • 373 cu ft heaped capacity per ASAE S324.2
  • A center drive shaft with a torque limiting clutch provides power and protection to the bottom driven monobloc gearbox.
  • Dual hydraulic cylinder guillotine/metering style endgate
  • Patented reverse flighting creates a more even spread pattern.
  • 1/2″ thick vertical beater flighting
  • 5/8″ marine log chain apron featuring a limited lifetime warranty.
  • 2″ x 3″ x 1/4″ heavy tubular apron slats
  • Replaceable beater blades
  • Removable beater assembly allows for stockpiling manure.
  • Constant velocity PTO
  • Poly side load bump rails
  • LED highway lighting



Specifications

Model
PS6138
Category Name
Agriculture
Year
2025
Sale Type
New
Manufacturer
H&S
Quantity
0
Manufacturer Qty
0
Hub
8,000 lbs.
Jack
Crank
Tire Size
425 × 22.5, 19L x 16.1, 550/45 × 22.5
PTO Choices
Choice of 1 ⅜″ or 1 ¾″ 1,000 RPM Constant Velocity
Inside Depth
30″ (76.2 cm)
Inside Length
177″ / (4.5 m)
Inside Width
73″ (185.4 cm)
Spindle Size
3″ (7.6 cm)
Overall Length
297″ (7.5 m)
Weight W/Tires
9,400 lbs.
Poly Bump Rails
Standard
Apron Chain Size
5/8″ Grade 80
Hydraulic Endgate
Hydraulic Guillotine/Metering Style
Side Loading Height
67″ (170.2 cm)
Cylinders On Endgate
2
Overall Width W/Tires
121″ (307.3 cm)
Vertical Beater Height
98″ (248.9 cm)
Vertical Beater Diameter
34″ (86.4 cm)
Replaceable Beater Paddles
Standard Number Of Beaters
2
Removeable Beater Assembly
Height - Top Of Hyd. Endgate
98.38″ (249.9 cm)
Inside Width - Top Of Flare
95″ (241.3 cm)
Spread Pattern - Approximate
25’ – 30’ dependent on the weight of material
Capacity – Heaped Bushel Per S324.2
300
Capacity Cu. Ft. Heaped Per ASAE S324.2
373.34
Capacity Cu. Ft. Struck Level Per ASAE S324.2
237

options

H&S PS6138 237 Cu. Ft. Struck Per ASAE S324.2 PowerSpread Manure SpreaderRubber Spring Suspension Package

Available to help cushion your load while traveling through the field for a smoother ride in the tractor while also preventing unnecessary wear on the hitch and pole.

H&S PS6138 237 Cu. Ft. Struck Per ASAE S324.2 PowerSpread Manure SpreaderMain Apron Reverser Valve Package

This option allows you to reverse the load away from the beater assembly if a foreign object should come in contact with the beaters.

H&S PS6138 237 Cu. Ft. Struck Per ASAE S324.2 PowerSpread Manure SpreaderHydraulic Actuator Light Covers

Light covers close when the guillotine/metering-style endgate is raised for spreading. Keeps lights clean for road travel.

H&S PS6138 237 Cu. Ft. Struck Per ASAE S324.2 PowerSpread Manure SpreaderFit-Around Screen Extension

Adds an extra 18" left and right and an extra foot above to help protect the tractor and operator.

H&S PS6138 237 Cu. Ft. Struck Per ASAE S324.2 PowerSpread Manure SpreaderElectric Adjust / Manual Hydraulic Variable Speed Apron Control



brochure

Name

Link
manure-spreader-brochure Download
