Hustler Raptor XD- 48"

Name: Hustler Raptor XD- 48"
Brand: Hustler
Availability: OutOfStock

The Raptor XD is the ideal zero-turn for homeowners with up to 5 acres of property ...

View In-Stock

Overview

The Raptor XD is the ideal zero-turn for homeowners with up to 5 acres of property. The up to 24hp Kawasaki horsepower and 60-inch deck option makes the XD a premium lawn mower in the residential zero-turn category. Like all Raptors, we’ve spent decades and thousands of hours perfecting our durable fabricated decks that provide a professional-grade cut-quality. Raptor XD’s are backed by an industry leading 3yr / 300hr warranty.

21.5hp, 23hp & 24hp Kawasaki Engines
42” 48", 54" & 60” decks
Up to 7.5 mph mowing speed
3-year / 300 hour limited warranty

Engine	Deck Sizes
21.5HP - Kawasaki FR651	42”, 48"
23HP - Kawasaki FR691	54”
24HP - Kawasaki FR730	60"

Specifications

Model

Raptor XD

Category Name

Zero Turn Mowers

Year

2025

Sale Type

New

Manufacturer

Hustler

Quantity

Manufacturer Qty

Gallery

features

Premium Seat

Premium bolstered high-back seat with armrests and built-in lumbar support.

Welded Steel Deck

Welded fabricated steel deck adds durability & extends mower's life. Up to 60" deck size available.

BigBite™ Rear Tires

We worked directly with the tire manufacturer on this design. You will not find them anywhere else.

key specs

WARRANTY

3 Year/300 hour residential

DRIVE_TIRE

20 x 8-10 BigBite™

FRONT_TIRE

13 x 6.5

TRANSMISSION

Hydro-Gear ZT-2800®

CUTTING_WIDTH

48"

FUEL_CAPACITY

3 gal.

CUTTING_HEIGHT

1.5" to 4.5"

ENGINE_HORSEPOWER

21.5

GROUND_SPEED_(FWD)

Up to 7.5 mph

ENGINE_MANUFACTURER

Kawasaki FR651

engine

COOLING

Air Cooled

DISPLACEMENT

726cc

ENGINE_WARRANTY

3 Year Warranty

ENGINE_HORSEPOWER

21.5

ENGINE_MANUFACTURER

Kawasaki FR651

drive system

TYPE

Dual Hydrostatic

TRANSMISSION

Hydro-Gear ZT-2800®

FUEL_CAPACITY

3 gal.

PARKING_BRAKE

Integrated with steering levers

GROUND_SPEED_(FWD)

Up to 7.5 mph

deck

SPINDLES

Aluminum with 1" shaft and double lip sealed ball bearings

DECK_LIFT

Foot Operated

DECK_DEPTH

4.5"

BLADE_LENGTH

16.50"

CUTTING_WIDTH

48"

DECK_MATERIAL

Fabricated 11 gauge steel

CUTTING_HEIGHT

1.5" to 4.5"

SPINDLE_MOUNTS

Reinforced 7 gauge steel

BLADE_TIP_SPEED

18,500

DECK_ENGAGEMENT

Ogura GT1.5

IMPACT_TRIM_AREA

3/8" x 1" steel bar

NUMBER_OF_BLADES

construction

FRAME

1.5" X 3.0" steel tubing

FRONT_AXLE

Fabricated with sealed ball bearings

FRONT_CASTER_FORK

Fabricated 3/8" steel

FRONT_CASTER_WHEEL

Sealed ball bearings

general

SEAT

Bolstered high-back seat with armrests and built-in lumbar support

CUP_HOLDER

dimensions

WEIGHT_(LBS)

627

HEIGHT_(INCHES)

43.7

LENGTH_(INCHES)

69.3

DRIVE_TIRE_(INCHES)

20 x 8-10 BigBite™

FRONT_TIRE_(INCHES)

13 x 6.5

WIDTH_W/_CHUTE_UP_(INCHES)

52.5

TIRE-TO-TIRE_WIDTH_(INCHES)

PRODUCTIVITY_(ACRES_PER_HOUR)

2.91

dimensions with catcher

CATCHER_STYLE

2-bag

CATCHER_CAPACITY

5.4 bushel

POWERED_/_NON-POWERED

Non-powered

MOWER_WIDTH_W/_CATCHER

63.5

MOWER_LENGTH_W/_CATCHER

91.4

literature

Name	Link
Specs PDF	Download
Brochure PDF	Download

Documents

63b6f43300c40105446aeed0_2023_HU_Raptor Series_2023.pdf
HUS_2024_Brochures_Residential_Mowers_Final_DIGITAL_4_5.pdf
