Hustler TrimStar-48"

Name: Hustler TrimStar-48"
Brand: Hustler
Availability: OutOfStock

A Walk-Behind With Maximum Stability, Ease-Of-Control ...

View In-Stock

Overview

A Walk-Behind With Maximum Stability, Ease-Of-Control.

Hustler's TrimStar® is a perfect addition to any commercial mower fleet. It makes access to hard-to-reach spots easy and is designed to help reduce operator fatigue.

15hp - 23hp Kawasaki Engines
36", 48", 54” & 60” decks
Up to 6.3 mph mowing speed
5 Year / 1200 Hour (First 2 Years No Hour Limit)

Engine	Deck Sizes
15HP - Kawasaki FS541 (Electric Start)	36”
18.5HP - Kawasaki FS600 (Electric Start)	48”
22HP - Kawasaki FS651 (Electric Start)	54”
23HP - Kawasaki FS691 (Electric Start)	60”

Specifications

Model

TrimStar

Category Name

Zero Turn Mowers

Year

2025

Sale Type

New

Manufacturer

Hustler

Quantity

Manufacturer Qty

Gallery

features

H-Bar® Steering

Patented steering is the easiest-to-use walk-behind system in the field, reducing operator fatigue.

Deck Lift

Easy-to-operate deck lift makes deck height adjustment a breeze.

Dual Hydro System

Heavy-duty traction and performance.

Service Friendly Design

Designed to make maintenance and service simple and easy.

Welded Steel Deck

Durable 10 ga. plus 11ga. reinforced steel with 11 ga. formed channel rolled edge. (36" deck model is 7ga. with 7ga. reinforced steel)

key specs

WARRANTY

5 Year / 1200 Hour (First 2 Years No Hour Limit)

DRIVE_TIRE

20 x 8-10

FRONT_TIRE

11 x 4-5

TRANSMISSION

Hydro-Gear ZT-2800®

CUTTING_WIDTH

48"

FUEL_CAPACITY

3.4 gal.

CUTTING_HEIGHT

1.5" to 4.5"

ENGINE_HORSEPOWER

18.5

GROUND_SPEED_(FWD)

Up to 6.3 mph

ENGINE_MANUFACTURER

Kawasaki FS600

engine

COOLING

Air Cooled

AIR_CLEANER

Oval canister, dual element

DISPLACEMENT

603cc

ENGINE_WARRANTY

3 Year Limited

ENGINE_HORSEPOWER

18.5

ENGINE_MANUFACTURER

Kawasaki FS600

drive system

TYPE

Dual Hydrostatic

TRANSMISSION

Hydro-Gear ZT-2800®

FUEL_CAPACITY

3.4 gal.

PARKING_BRAKE

Internal transmission mechanical brake

HYDRAULIC_COOLING

Pump mounted fan

GROUND_SPEED_(FWD)

Up to 6.3 mph

RESERVOIR_CAPACITY

2 qts per side

deck

SPINDLES

Aluminum with steel shaft and sealed ball bearings

DECK_LIFT

Hand Operated

DECK_DEPTH

BLADE_LENGTH

16.50"

CUTTING_WIDTH

48"

DECK_MATERIAL

10ga + 11ga reinforced steel

CUTTING_HEIGHT

1.5" to 4.5"

SPINDLE_MOUNTS

Reinforced 11 ga.

BLADE_TIP_SPEED

18,500

DECK_ENGAGEMENT

Electric PTO Clutch

IMPACT_TRIM_AREA

11ga formed channel rolled edge

NUMBER_OF_BLADES

construction

FRAME

1.5" x 2" steel tubing

FRONT_AXLE

Fabricated with tapered roller bearings

FRONT_CASTER_FORK

Fabricated 3/8" steel

FRONT_CASTER_WHEEL

Tapered wheel bearings and debris cap

general

CUP_HOLDER

dimensions

WEIGHT_(LBS)

635

HEIGHT_(INCHES)

42.5

LENGTH_(INCHES)

DRIVE_TIRE_(INCHES)

20 x 8-10

FRONT_TIRE_(INCHES)

11 x 4-5

WIDTH_W/_CHUTE_UP_(INCHES)

TIRE-TO-TIRE_WIDTH_(INCHES)

PRODUCTIVITY_(ACRES_PER_HOUR)

2.44

warranty

Warranty

5 Year / 1200 Hour (First 2 Years No Hour Limit)

dimensions with catcher

CATCHER_STYLE

Side Catcher

CATCHER_CAPACITY

3.5 bushel

POWERED_/_NON-POWERED

Powered

MOWER_WIDTH_W/_CATCHER

68.7"

MOWER_LENGTH_W/_CATCHER

74.55"
