Hustler Super 104-104"

Name: Hustler Super 104-104"
Brand: Hustler
Availability: OutOfStock

104 Inch Width Of Cut Makes Big Jobs Easy ...

View In-Stock

Overview

104 Inch Width Of Cut Makes Big Jobs Easy.

Hustler's Super 104™ can easily handle acres of work. Offering a 104" width of cut, zero-turn precision and up to an impressive 11 mph speed, this machine is in a class by itself.

38.5 - 40hp Vanguard & Kawasaki Engines
104" deck
Up to 11 mph mowing speed
5 Year / 1200 Hour (First 2 Years No Hour Limit)

Engine	Deck Sizes
38.5HP - Kawasaki FX1000 EFI	104” RD
40HP - Vanguard BigBlock EFI w/ Oil Guard	104” RD

Specifications

Model

Super 104

Category Name

Zero Turn Mowers

Year

2025

Sale Type

New

Manufacturer

Hustler

Quantity

Manufacturer Qty

Gallery

features

Unmatched Comfort

I3M suspension seat with 3-inch travel range.

HyperDrive Hydro System

A Hustler® exclusive, industrial pumps and high torque wheel motors, 3-gallon reservoir, oil cooler and hot oil shuttle.

104" Width of Cut

The widest and most productive of any commercial zero-turn mower.

Wings Fold To 80"

80" transport width fits most trailers for easy travel between jobs.

key specs

WARRANTY

5 Year / 1200 Hour (First 2 Years No Hour Limit)

DRIVE_TIRE

26 x 12-12

FRONT_TIRE

15 x 6-6

TRANSMISSION

Danfoss DDC20 pumps with Parker TG wheel motors

CUTTING_WIDTH

104"

FUEL_CAPACITY

12 gal.

CUTTING_HEIGHT

1" to 5.5"

ENGINE_HORSEPOWER

40, 38.5

GROUND_SPEED_(FWD)

Up to 11 mph

ENGINE_MANUFACTURER

Vanguard BigBlock EFI Oil Guard, Kawasaki FX1000 EFI

engine

COOLING

Air Cooled

AIR_CLEANER

Remote Canister

DISPLACEMENT

993cc (Vanguard), 999cc (Kawasaki)

ENGINE_WARRANTY

3 year warranty

ENGINE_HORSEPOWER

40, 38.5

ENGINE_MANUFACTURER

Vanguard BigBlock EFI Oil Guard, Kawasaki FX1000 EFI

drive system

TYPE

Dual Hydrostatic

TRANSMISSION

Danfoss DDC20 pumps with Parker TG wheel motors

FUEL_CAPACITY

12 gal.

PARKING_BRAKE

Integrated with steering levers

HYDRAULIC_COOLING

Oil Cooler w/9" fan

GROUND_SPEED_(FWD)

Up to 11 mph

RESERVOIR_CAPACITY

3 gallons

deck

SPINDLES

Ductile cast iron with steel shaft and sealed ball bearings

DECK_LIFT

Hydraulic powered

DECK_DEPTH

5.5"

BLADE_LENGTH

23.86" - 20.5"

CUTTING_WIDTH

104"

DECK_MATERIAL

11 gauge welded steel

CUTTING_HEIGHT

1" to 5.5"

SPINDLE_MOUNTS

Reinforced 7 ga doubler

BLADE_TIP_SPEED

Wing Decks: 15,800; Center Deck: 15,500

DECK_ENGAGEMENT

Electric PTO Clutch

IMPACT_TRIM_AREA

1.5" x .375" steel bar

NUMBER_OF_BLADES

construction

FRAME

1.5" X 3" steel tubing

FRONT_AXLE

Fabricated w/ tapered roller bearings

FRONT_CASTER_FORK

Fabricated 1/2" steel

FRONT_CASTER_WHEEL

Tapered wheel bearings and debris cap

general

SEAT

I3M Suspension Seat (adjustable armrests & back)

CUP_HOLDER

dimensions

WEIGHT_(LBS)

2500

HEIGHT_(INCHES)

54" (71.5" w/ ROPS)

LENGTH_(INCHES)

95.5"

WING_TIRE_(INCHES)

11 x 4 semi-pneumatic

DRIVE_TIRE_(INCHES)

26 x 12-12

FRONT_TIRE_(INCHES)

15 x 6-6

WIDTH_W/_CHUTE_UP_(INCHES)

106.1 wings down, 80" wing up at gauge wheel, 72.5" wings up at deck base

TIRE-TO-TIRE_WIDTH_(INCHES)

60.3

PRODUCTIVITY_(ACRES_PER_HOUR)

9.24

literature

Name	Link
Specs PDF	Download
Brochure PDF	Download

warranty

Warranty
