Case IH 2150 Front Fold Trailing

  • Case IH 2150 Front Fold Trailing
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

6 - 48 Rows
2000 Series Early Riser Planters

From the rugged row unit to the factory integration of the industry’s most accurate planter technologies, the 2000 series operates at your speed to ensure faster, more uniform emergence and the best yield possible.

Case IH 2150 Front Fold Trailing 2150 Front Fold Trailing

A 12-, 16, and 24-row planter with 30 inch spacing that requires anywhere from 180-500 engine hp based on planter size and desired speed.

Quick Specs

  • Row options: 12, 16 or 24-row
  • Row Spacings: 30" spacing
  • Frame Size: 7x7
  • Sections: 3
Specifications
Model
2150 Front Fold Trailing
Year
2023
Sale Type
New
Manufacturer
Case IH
Closing System
9" (229) Inverted discs and press wheel
Standard Seed Drive
Precision Planting vDrive electric motor, each row
Depth Gauging System
Adjustable T-handle, 1/4" or 1/8" increments
Row Spacings - In (mm)
30 (762)
First Monitor Available
AFS Pro 700
Frame Rigid Or Flexible
Wing flex +/- 21 degrees
Number Of Frame Sections
3
Drawbar/Hitch Requirement
Two-point hitch
Power Needed - Minimum Hp
155
Planting Width - Ft-in (m)
30' (9.14)
Standard Down Force Method
Air down force w/gauge wheel feedback
Metering Device, First Option
Precision Planting vSet 2 vacuum
Seed Delivery, Meter To Furrow
Gravity drop w/10 LED seed sensor
Residue Tine Wheels, Row Cleaners
Fixed, floating or Precision Planting Clean Sweep air cylinders
Bulk-Fill Or Individual Row Hoppers
Two Bulk-Fill Hoppers
Standard Hopper Capacity, Per Hopper Bu (US)
50
Hookup To Tractor, Mounted, Semi-mounted, Trailing
Trailing
literature
2000 Series Early Riser Planter (127.58 MB)                                                                                                                                             Download
Climate Fieldview (4.17 MB)                                                                                                                                                                          Download
